| BRAND | Ascon |
| Product | XE-301 |
| Description | XE series digital controller (unconfigured) |
| Internal code | OTC1497527 |
| Weight | 1.361 |
| Technical specification | -Supply voltage: 100.. 240 V, 50/60 -serial interface: without -Dimensions: 96 x 48 mm DIN, depth 120 mm - Input (configurable): *PT 100 *Thermocouple (L, J, K, S) *Standard signal 0 (4)... 20 mA or 0... 1 (10) V - Output (hardware): *Main output Y1: relay or logic (configurable) *Auxiliary output Y2: alarm relay *Auxiliary output Y3: relay for alaram or control Control behavior (configurable) *PID control with self-optimization *ON/OFF hysteresis control control characteristic *Heating or cooling characteristics with up to 2 alarm outputs or Heating or cooling characteristic with an alarm output - Simultaneous display of setpoint and actual value - Control output configurable as relay or logic signal - Ramp function (one setpoint ramp each for rising and falling setpoints) - power limitation - scalable inputs for standard signals - Configuration via front buttons - voltage output for external 24 V transmitters - parameter lock - Front protection: IP 54, with transparent cover IP 65 (optional) |
