| BRAND | Foxboro (by Schneider Electric) |
| Product | IAP10-D22C1F-M2L1 |
| Description | Pressure Transmitters |
| Internal code | OTC2490 |
| Weight | 1 |
| Technical specification | (Model Code: IAP10-D22C1F-M2L1 FUNCTION: IAP10 Measures Pressure And Transmits A Proportional Electrical Signal. ELECTRONIC VERSION AND OUTPUT SIGNAL: D Intelligent; Digital FoxCom Or 4 To 20 mA, Configurable STRUCTURE CODE MATERIALS AND TYPE: 22 316L ss Process Connection, 316L ss Diaphragm, Silicone Fill Fluid, 1/2 NPT External & 1/4 NPT Internal Thread Connection Type SPAN LIMITS: C 0.007 And 0.21 MPa, 1 And 30 psi, 0.07 And 2.1 bar or kg/cm² CONDUIT CONNECTION & HOUSING MATERIAL: 1 1/2 NPT Conduit Connection, Both Sides, Aluminum Housing ELECTRICAL SAFETY: F FM Intrinsically Safe For Class I, Division 1, Groups A, B, C, & D; Class II, Division 1, Groups E,F, & G; And Class III, Division 1. Also Class I, Division 2, Groups A,B,C, & D; Class II, Groups F & G; And Class III, Division 2. Explosionproof For Class I, Division 1, Groups B,C, & D; Dust-Ignitionproof For Class II, Division 1, Groups E,F,G; And Class III, Div 1. OPTIONAL MODEL SUFFIX(ES) INCLUDED: M2 316 ss Bracket with Stainless Steel Bolts for use with 1/2 NPT L1 Digital Indicator, Internal Pushbuttons, And Window Cover) |
