Prices 942530 / FF-040GR015S-942530 Honsberg Ukraine

BRAND	Honsberg
Product	942530 / FF-040GR015S-942530
Description	Flow Switch
Internal code	OTC277529
Weight	1
Custom code	85365080
Technical specification	flow monitor nominal size: DN 40 Connection: internal thread G 1½ Case: gunmetal, nickel-plated Pressure resistance: PN 16 Internal parts: POM Seal: NBR Media temperature: -20... +90 °C Ambient temperature: -20... +70 °C Adjustment range: SC piston Switch point: 1.5 l/min H2O falling off, 1.7 l/min rising Switch head: nickel-plated brass El. Connection: PG with 1.8 m cable El. Contact: reed switch Contact rating: 230 V AC 1 A 50 VA Connection diagram: Closer, connection diagram No. 0.212 Protection class: IP65 Flow direction: Horizontal from left System Cleaners 942530

You can find the current prices belongs to Honsberg - 942530 / FF-040GR015S-942530 coded Flow Switch product. You can ask all the codes and references except 942530 / FF-040GR015S-942530 too. All of the listed products are with guaranteed origin and high quality. Thanks to our partner network in and abroad we will provide you with competitive prices and short delivery times for 942530 / FF-040GR015S-942530 Honsberg . We present you the most competative price and delivery time on 942530 / FF-040GR015S-942530 referenced product.
