Prices ATMOS D10-KR Var. 0102 Baratti Ukraine

BRAND	Baratti
Product	ATMOS D10-KR Var. 0102
Description	Reciprocating fan pressure mode
Internal code	OTC4746639
Weight	600
Custom code	84141025
Technical specification	- absolutely oil-free and wear-free compression - Labyrinth sealing to the compressor chamber with relief hole - air-cooled, V-belt drive with belt protection - Intake muffler including integrated intake filter - two-stage exhaust muffler - including pressure relief valve - including exhaust side connector, rubber sleeve and two mounting clamps - including glycerin-filled tube spring pressure gauge D = 63mm (0... 1.6bar) Technical data in general: Suction volume: 120 to 1500m3/h (15 to 75Hz) Pressure increase (continuous/intermittent): 1.4/1.8 bar abs. Fan speed: 800 to 4500min -1 (15 to 75Hz) Valve diameter DN: 100/150 Outer diameter of exhaust air outlet: 114.3 mm Inner diameter of rubber sleeve: 110mm Noise level (speed/depending on pressure) approx.: 80db (A) dB (A) (after free-field measurement DIN 45635) For dimensions, see measurement sheet no.: 900047AB Technical data for your application: Suction volume: 1130 m³/h max. overpressure: 760 mbar Safety valve set to: 800 mbar Fan speed: 2750 rpm Motor: 30 kW, 3x 400 V 50 Hz KRS engine: SPB 150-3r, TL 2517, 55mm KRS blower: SPB 160-3r, TL 2517, 40mm V-belts: XPB 1450 (3 pcs)

Baratti - ATMOS D10-KR Var. 0102 referenced Reciprocating fan pressure mode product produced by high technology.
If you need other products from Baratti, please send us an inquiry by e-mail. Our company supply ATMOS D10-KR Var. 0102 referenced product fastest and securest on your request. Thanks to our large disturbiton network, we offer door delivery in most suitable conditions. ATMOS D10-KR Var. 0102 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.

Where can I buy ATMOS D10-KR Var. 0102 by Baratti in Ukraine?

You can purchase ATMOS D10-KR Var. 0102 by Baratti from ТОВ "ОДЕСА ТЕХНІК". We serve customers across Ukraine, offering competitive prices and reliable service.

What is the price of the ATMOS D10-KR Var. 0102?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of Baratti in Ukraine?

While we are not the official distributor or seller of Baratti in Ukraine, we source our products from reliable channels and offer you original Baratti equipment at competitive prices.

How can I access ATMOS D10-KR Var. 0102 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for ATMOS D10-KR Var. 0102 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for ATMOS D10-KR Var. 0102?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
