Prices 995150302000001 Ephy Mess Ukraine

BRAND	Ephy Mess
Product	995150302000001
Description	Harness, AVE transmission/Gearbox
Internal code	OTC4226171
Custom code	90259000
Technical specification	2Pt100, 2 conductor circuit Class B ±0.3°C at 0°C according to DIN EN 60751 A - el=80mm, kl=1060mm B - EL=26mm, kl=1280mm Harting HAN HPR 3 with HAN Q5 (RoHS Compliant) Cable: Shielded Hose Line 2x [4xAWG 24/7 Cu-Silver-Plated/STP/Polyester Film/Cu-tinned/STPAØ: 4.2mm] BK (RD/RD/WH/WH) Plastic corrugated pipe hose Aø=10mm VCST-07B, Measuring range ፦40°C... +125°C Ambient temperature ፦40°C... +125°C Insulation resistance: ≥ 200 MΩ/500 VDC Shielding use on the sensor side: screen not attached to the sensor housing Umbrella use on the connection side: screen mounted on the plug housing 2 x 2-wire circuit merged on Harting plug 5-pin with 4 pin contacts, without pipe clamps and screws, only with sensor head screws AL: N/ECCN: N

Ephy Mess - 995150302000001 referenced Harness, AVE transmission/Gearbox product produced by high technology.
995150302000001 became irreplaceable of foundations. 995150302000001 referenced product which is satisfy the customer's needs, offers advantages of quality and cost. It produced result of tests of laborotory for years. 995150302000001 referenced product is an original piece of your foundation or machine, original parts makes your machine live longer.
