BRAND | Analytec |
Product | 35125004 |
Description | Opto small limit switch |
Internal code | OTC4855578 |
Custom code | 85365019 |
Technical specification | 14441447 OLS-C20 M16x1.5 3m PVC SE OLS-C optolectronic liquid limit sensor old Phoenix type: 720.0020SE-59K3P old material no.: 500224 new product number: 35125004 Maximum pressure: 50 bar Temperature, fluid, max.: 135°C Min. fluid temperature: -30°C Process connection: M16 x 1.5 Wrench size: SW 24 Switching direction: switching immersion (SE) (Closer when the level rises) Material stainless steel 1.4571 Any installation position Output: O.C. PNP transistor, short-circuit proof, Current, voltage and power limits Electr. 3 m 3-pin PVC cable connected Operating power: 24 VDC Protection class: IP66 |
